Scott Scale RC Team

KEY FEATURES:

- Scale Carbon HMF Frame
- RockShox SID SL RL 100mm
- RideLoc 2 Remote
- Shimano XT 12 Speed
- Shimano XT Disc Brakes
- Schwalbe Racing Foldable Tires

The ALL-NEW Scale RC Team is the perfect blend of stiffness, light weight, and 30 years of carbon expertise. These characteristics, encompassed in an uncompromising frame design decisively accelerate the Scale away from the pack with every pedal stroke. Whenever you find yourself up against the clock, tip the scales in your favor.

TECHNOLOGIES:

ADJUSTABLE HEAD ANGLE
With the new Scale RC, you can adjust the head angle by 0.6 degrees slacker or steeper. This can be done without cutting cables or bleeding brakes. All you must do is disassemble the bar, rotate the headset cups 180 degrees, and reassemble.

DESIGN
The new Scale’s design was uncompromisingly subjected to our pursuit of perfection and drive for pure efficiency, strictly following the guiding principle of "Form follows Function". In our search for the ultimate, yet most simple construction, we’ve centered the design around the essentials by balancing the bike’s DNA in order to create a whole new breed of XC bike. The result is a straightforward and clear design, which provides the all-new Scale with its distinctive character and aggressive look: a bike that proudly shows off its characteristics.

HOLLOW DROPOUT CONSTRUCTION
The dropout features an advanced, hollow construction, which allows the axle head to clamp against the inner surface of the dropout and leaves the head flush with the surface. This enables the lightest possible construction approach and a clean-looking design from the outside. While being able to directly shave off 7.5g with the new dropout construction, the optimized design favors a narrower construction of the rear triangle area, which in turn enables a reduction of 20g in this area of the frame (HMX-SL).

MONOCOQUE CONSTRUCTION
The new Scale RC’s monocoque construction enables production using only one mold for the main section of the bike, the front triangle. Applying our carbon expertise, the new Scale, therefore, consists of only 3 separate pieces molded together. This directly translates into an increased level of efficiency due to the reduced number of junctions required therefore decreasing weight while keeping superior stiffness – something we’re always aiming for with hardtail race bikes. With the full frame constructed as a system, the monocoque design enables the frame to handle forces as a whole.

SERVICE DOOR
A little service door, which is accessible through a downtube cover, allows easy access to the interior of the frame without the need to remove the Bottom Bracket. Frame maintenance is made easy with regards to cable routing.

SPECS
